The virtual short uses two properties of an ideal op-amp: Although virtual short is an ideal approximation, it gives accurate values when used with heavy negative feedback. As long as the op-amp is operating in the linear region not saturated, positively or negatively , the open loop voltage gain approaches infinity and a virtual short exists between two input terminals.

Because of the virtual short, the inverting input voltage follows the non-inverting input voltage. If the non-inverting input voltage increases or decreases, the inverting input voltage immediately increases or decreases to the same value. Therefore, for a non-inverting amplifier circuit, the input impedance is given by the equation,. Voltage follower is one of the simplest uses of an operational amplifier, where the output voltage is exactly same as the input voltage applied to the circuit. In other words, the gain of a voltage follower circuit is unity.

The output of the op-amp is directly connected to the inverting input terminal, and the input voltage is applied to the non-inverting input terminal. The voltage follower, like a non-inverting amplifier, has very high input impedance and very low output impedance. The circuit diagram of a voltage follower is shown in the figure below. It can be seen that the above configuration is same as the non-inverting amplifier circuit, with an exception that there are no resistors used.

The gain of a non-inverting amplifier is given as,. In the voltage follower, the resistor R1 is equal to zero and R2 is infinite. So the gain of the voltage follower will be equal to 1. A Voltage follower is also commonly known as a Unity Gain Buffer. The voltage follower or unity gain buffer circuit is commonly used to isolate different circuits, i.
